Yanmar Trash Pump YDP20TW-E4, 250 GPM, Tier IV Diesel
YANMAR Diesel powered, portable, high volume, self priming trash pumps come standard with a cast iron impeller to resist abrasion. They feature one tool serviceability for
easy clean out. All pumps feature an aluminum housing, cast iron wearparts, built in check valve, suction strainer and painted heavy duty steel roll frame. The pumps also
feature heavy duty cast iron flanges with male NPT threads. The flanges can be rotated in 90 degree increments and come with an easy access fill plug on the discharge. The engine is a L70W Final Tier IV engine that comes standard with both recoil start and electric start capabilities.
Key Features
- 2″ trash pump
- Cast aluminum with cast iron wear parts
- Silicon carbide / viton mechanical seal
- EPDM / EPR O-Rings
- 2”, 3”, or 4” removable male NPT suction and discharge ports
- Discharge rotates in 90 degree increments
- Easy clean out with one tool serviceability
- Maximum solids handling up to 1-1/4”
- Maximum flow up to 250 GPM
- Maximum head up to 110 ft
- Self priming to 26 ft
- Optional Wheel Kit and Hose Kit available
Standard Features
- Cast iron impeller
- Electric start and recoil start
- One tool pump serviceability
- Silicon carbide mechanical seal with graphite impregnated seat and viton elastomers
- Heavy duty steel roll frame and strainer included
- Built in EPDM/EPR check valve
- Removeable / Replaceable cast iron suction and discharge ports
- Discharge port rotates in 90 degree increments
- Vibration dampening feet
- Maximum fluid temperature of 180 degrees Fahrenheit
